Standard equipment :
hydraulic workpiece clamping ,1 saw blade belt ,material support stand ,coolant system ,work lamp,operation manual
|
SPECIFICATIONS |
Units |
GHZ4240 |
GHZ4250 |
|
90°Circular |
mm |
400 |
500 |
|
90°Rectangular |
mm |
550*400 |
630*500 |
|
45°Circular |
mm |
300 |
400 |
|
45°Rectangular |
mm |
400*300 |
500*400 |
|
Blade speed |
m/min |
27,45,69 |
27,45,69 |
|
Blade size |
mm |
5050*41*1.3 |
5880*41*1.3 |
|
Main motor power |
kw |
5.5 |
5.5 |
|
Hydraulic motor power |
kw |
1.5 |
1.5 |
|
Coolant motor power |
kw |
0.125 |
0.125 |
|
Machine weight |
kg |
1600 |
1900 |
|
Overall dimension |
mm |
2460*1950*2000 |
2960*2150*2200 |
