l different speeds and a wide cutting scope.
l a high-efficiency arc-push saw which is one and a half times more efficient than that of normal sawing machines
l a new style V-shaped transmision belt which is very quiet(no louder than 74db)
l electrical components are installed inside, thus gidving it an elegant outer appearance and rendering if extremely safe.
l Auto cutting process except gripping device and feeing mechanism.With Protective System.
l Hydraulic transmission simple running Easy upkeep
|
Model |
HS7125 |
|
|
Cutting capacity |
Round bar |
250mm |
|
Square bar |
220x220mm |
|
|
Oblique saw |
45° |
|
|
Sawing speed (Time/Minute) |
43,50,60,86,100,120 |
|
|
Blade size |
450x45x2.25mm |
|
|
Main motor |
3.22kw |
|
|
Coolant pump motor |
0.04kw 2step |
|
|
Saw blade rapid down |
0.25kw 4step |
|
|
Packing size |
2000x950x1300mm |
|
|
N.W./G.W. |
600/830kg |
|
