Main data |
CT16 |
|
|
Max.slot-cutter length |
≤125（travel）≤100mm |
|
|
Punching times/min |
≤165(travel)≤100mm |
|
|
Puching times and change grade |
The same as horizontal spindle transmission system of milling machine |
|
|
Horizontal turning direction |
clockwise |
|
|
Swing angle of carriage |
±90° |
|
|
Distance from slot-cutter shaft to machine column |
315,330,380 |
|
|
Installation size |
Machine connection spindle taper |
ISO40 ISO50 MT4 |
|
Machine vertical guide angle |
Rectangular guide rail and 55°、60°dovetai |
|
|
Machine vertical guide width |
200,250,260,280,300,320,360 |
|
|
Diameter of fixed plate |
130,140,165,190 |
|
