1. Maximum Machining Diameter: φ360 mm
2. Maximum Machining Module: 10 mm
3. Maximum Tool Holder Rotation Angle: ±45 degrees
4. Machinable Number of Teeth Range: Any
5. Maximum Machining Width: 450 mm
6. Maximum Hob Cutter Mounting Diameter: φ170 mm
7. Maximum Hob Cutter Mounting Length: 200 mm
8. Hob Cutter Spindle Taper: 1:10
9. Interchangeable Hob Cutter Arbor Diameters: 27, 32, 40, 50 (one of each provided)
10. Worktable Diameter: 360 mm
11. Worktable Bore Diameter: 75 mm
12. Distance from Worktable Surface to Machine Bed Base: 1130 mm
13. Horizontal Distance from Hob Cutter Center to Worktable Center: 40–310 mm
14. Vertical Distance from Hob Cutter Center to Worktable Surface: 180–680 mm
15. Distance from Rear Column Center to Worktable Surface: 370–920 mm
16. Maximum Hob Cutter Axial Travel: 190 mm
17. Hob Cutter Spindle Speed Range (B-axis): 60–600 rpm (stepless)
18. Axial Feed Speed Range (Z-axis): 1–1000 mm/min (stepless)
19. Radial Feed Speed Range (X-axis): 1–2000 mm/min (stepless)
20. Tangential Feed Speed Range (Y-axis): 1–2000 mm/min (stepless)
21. Worktable Rotation Speed Range (C-axis): 1–100 rpm
22. Maximum Tool Holder Rotation Speed: 2°/s
23. CNC System: SINUMERIK 828D CNC System
24. Linear Axis Resolution: 0.001 mm
25. Rotary Axis Resolution: 0.001°
