4. Gear driven, with 3 cutting speed
5. Strong structure for big capacity cutting
6. Electric coolant system for extending the life of blade and improve the precision of work piece
7. High-capacity due to controlled by motor
8. Has the advantage of quickly clamping
9. The falling speed of saw bow is controlled by hydraulic cylinder
10. With a sizing device, machine will stop automatically after sawing materials
11. With power break protection device, machine will power off automatically when the rear protective cover is opened
Model |
BS-912G |
BS-912B |
Max |
Circular @90 o |
229mm (9" ) |
229mm (9" ) |
|
Rectangular @ 90 o |
178x305mm (7" x8.25" ) |
178x305mm (7" x8.25" ) |
Capacity |
Circular @ 45 o |
150mm (6" ) |
150mm (6" ) |
|
Rectangular @ 45 o |
127x150mm(5" x6" ) |
127x150mm(5" x6" ) |
Blade speed |
60HZ |
38, 78, 115 MPM |
32,60,88,115MPM |
50HZ |
31, 65, 95 MPM |
26,50,73,95MPM |
Blade size |
27x0.9x2655mm |
27x0.9x2655mm |
1.06" x0.036" x104.5" |
1.06" x0.036" x104.5" |
Motor |
1.1kW(1.5HP) 50/60HZ |
1.1kW(1.5HP) 50/60HZ |
Drive |
Gear |
V-belt |
Packing Size |
160x62x115cm |
160x62x115cm |
NW/GW |
200/252KGS |
230/260KG |
Model |
BS-912GR |
Max |
Circular @90 o |
229mm (9" ) |
|
Rectangular @ 90 o |
178x305mm (7" x12" ) |
Capacity |
Circular @ 45 o |
150mm (6" ) |
|
Rectangular @ 45 o |
127x150mm(5" x6" ) |
Blade speed |
60HZ |
38, 78, 115 MPM |
50HZ |
31, 65, 95 MPM |
Blade size |
27x0.9x2655mm |
1.06" x0.036" x104.5" |
Motor |
1.1kW(1.5HP) 50/60HZ
1.5KW 2HP (1ph) |
Drive |
Gear |
Packing Size |
160x62x115cm |
NW/GW |
220/260KGS |
Standard accessories:
Blade
Clamping vice
Electric coolant system
