Item |
Unit |
X6328B |
|
Table size |
Mm |
1120x260 |
|
Table travel |
mm |
600x270x300 |
|
Number-width-distance of T-slot |
|
3-14-63 |
|
Distance between spindle nose and table surface |
mm |
100-400 |
|
Distance between spindle axis and column surface |
mm |
100-650 |
|
Spindle travel |
mm |
127 |
|
Spindle taper (V/H) |
|
ISO40 |
|
Spindle speed range |
Rpm |
65-4660(V) /38-1310 (H) |
|
Spindle motor power |
kw |
2.2 |
|
Overall dimension |
mm |
1710x1480x2100 |
|
Machine weight |
kg |
1350 |
