Model |
TOK25 |
|
Max Drilling Diameter.(mm) |
Φ25mm(1”) |
|
Motor Power |
1100W |
|
Spindle Travel(mm) |
119 |
|
Class Of Speed |
12 |
|
Speed 50/60Hz |
150-2450/180-2940R.P.M. |
|
Spindle Taper |
MT3 |
|
Max. distance from spindle axis to surface of column(mm) |
218 |
|
Max. distance from spindle end to surface of table(mm) |
762 |
|
Max. distance from spindle end to surface of base(mm) |
1235 |
|
Swing(mm) |
436 |
|
Table Size(mm) |
350X350 |
|
Base Size(mm) |
465X350 |
|
Column Diameter(mm) |
Φ92 |
|
Height(mm) |
1690 |
|
Net Weight/Gross Weight(kg) |
86/91 |
|
Packing Size(mm) |
1415X645X300 |
