Model |
Unit |
ZX32G |
|
Max. Drilling diameter |
mm |
31.5 |
|
Max.tapping capacity |
mm |
M24 |
|
Diameter of column |
mm |
100 |
|
Max.spindle travel |
mm |
150 |
|
Distance spindle axis to column surface |
mm |
265 |
|
Distance spindle bore to worktable surface |
mm |
520 |
|
Distance between two column axis |
mm |
650 |
|
Spindle taper |
|
MT 3 |
|
Spindle speed |
R/min |
285-1875 |
|
Spindle speed numbers |
Step |
5 |
|
Wortable size |
mm |
2350x600 |
|
Overall height |
mm |
1850 |
|
Net weight |
kg |
1650 |
