Model |
Zx45 |
|
Max.drilling diameter |
45/32mm Iron/steel |
|
Max.face milling diameter |
80mm |
|
Max.end milling diameter |
32mm |
|
Table size |
800x240mm |
|
X,Y axes travel on worktable |
190/560mm |
|
Spindle taper |
MT4,R8, MT3 |
|
Spindle travel |
120mm |
|
Spindle speed |
75,170,280,540,960,1600 rpm |
|
Max.distance spindle to table |
460mm |
|
Head tilt left and right |
+/- 45 degree |
|
Power and speed of motor |
1.5kw 1450 rpm |
|
N.W/G.W |
325/350 kgs |
|
Package size |
850x760x1150 mm |
