• Drilling, tapping, boring, reaming ；
•Strong column,Vice table,Gear drive, lower noise
•Heavy-duty tapered roller bearing spindle,Positive spindle lock
|
Model |
Unit |
Z5040 |
|
Max.drilling capacity(iron/steel) |
mm |
40 |
|
Max.tapping capacity(iron/steel) |
mm |
24/20 |
|
Spindle taper |
Morse |
MT4 |
|
Worktable size |
mm |
560x560 |
|
Dimensions of base |
Mm |
730x500 |
|
Spindle travel |
Mm |
180 |
|
Distance between spindle center and center of column |
mm |
350 |
|
Distance from spindle nose to table surface |
Mm |
770 |
|
Distance from spindle nose to base parts |
Mm |
1210 |
|
The diameter of column |
Mm |
150 |
|
Max.swivel angel of worktable |
° |
90° |
|
Spindle speeds range , two step motor |
Rpm |
50-1450 18steps |
|
The feed of spindle |
mm/r |
0.1/0.2 |
|
Coolant of motor |
W |
60 |
|
Main Motor power |
Kw |
1.5 |
|
Net weight and gross weight |
Kg |
550/600 |
|
Package size |
mm |
2230x580x1100 |
